Aggregate Wash Plant

Aggregate wash plant has a variety of functions such as cleaning, screening, dehydration and recovery after unique innovation and reasonable design.

LDHB aggregate wash plant can be widely used for mining, aggregate processing, piling mud, river dredging treatment, ceramic raw material processing, silica sand production and processing, various metal ore tailings processing, construction waste disposal and other industries.

How Aggregate Wash Plant Work

The materials are evenly fed to the back of the screen surface and cleaned in the trough-shaped structure. With the continuous increase of materials and the vibration of the screen surface, materials continue to enter the dewatering screen surface of the front end of the screen and complete the dewatering and screening operations under the action of vibration. The fine sand lost in this process is recovered by the fine sand recovery device to maximize the use of resources.


1. Modular structure. Cleaning, screening, dehydration, and fines recycling operations all be completed on one equipment.
2. The polyurethane plate structure is adopted on the rear of screen to form a water reservoir, and an additional weir is added to extend the material cleaning time and the material cleaning effect is better.
3. The longer screen surface is more conducive to sieving and dewatering.
4. Equipped with a fine sand recovery system to effectively recover fine sand lost during the washing process.


Model Feed Size (mm) Capacity (t/h) Screen Panel (mm) Hydrocyclone (mm) Power (kw) Weight (kg) Overall Size (mm)
XSX1860-100 ≤10 60-100 1200*2400 250*4 66 9000 6700*3300*3800
XSX1872-120 ≤10 80-120 1500*3000 300*4 90 10500 7900*3300*2300
XSX2472-140 ≤10 80-120 1800*4200 350*4 111 12500 8000*3900*4000
XSX3072-180 ≤10 120-180 1800*4200 350*6 134 16000 8000*4500*4000
