Wheel Bucket Sand Washer For Wet Sand Production Line

Wheel bucket sand washing machine is an indispensable cleaning and sorting equipment in wet sand production line, mainly used to clean and remove impurities and dust of finished sand. Because of the high efficiency of washing sand by wheel bucket sand washing machine and low rate of finished sand wave, it plays an important role in the current wet sand production line. The following briefly introduces the equipment knowledge of the key equipment in wet sand production line – wheel bucket sand washing machine, with the details as follows:

high-frequency-sand-washing-machine

Advantages of wheel bucket sand washing machine in wet sand production line:

  1. Compared with other types of sand washing machine, the loss of medium fine sand and stone powder in the sand and stone treatment process of wheel bucket washing machine is very small. The grading distribution and fineness modulus cleaned by the wheel bucket washing machine can meet the standard requirements of national building sand.
  2. Except for screen, there are few wear parts of wheel bucket sand washing machine, which has long service life and low failure rate.
  3. In the production and design of the wheel bucket sand washing machine, the impeller driven bearing device is isolated from water and water receiving materials, which greatly prevents the bearing from being damaged due to water, sediment and pollutants.

The working principle of wheel bucket sand washing machine

wash-plant-for-sand

When the wheel bucket sand washing machine is working, the power unit drives the impeller to rotate slowly after decelerating through reducer, triangle belt and gear. Sand and stone enter into the cleaning tank through the feeding tank, and the washing function is completed under the action of impeller. The cleaned aggregate of sand and stone is taken away by the blade, and finally poured into the discharge tank to complete the cleaning function of the sand and stone.

The sand washing machine is mainly used to clean and remove impurities in various sand and stone products, and to assist in the production of machine-made sand. The wheel bucket sand washing machine is mainly used in wet sand production line. The wheel bucket sand washing machine can not only be used after the sand machine, but also widely used to remove soil, stone and other impurities in river sand, silt sand and weathered sand. The finished sand and stone after washing can be widely used in sand field, mixing station and various projects.
