Sand Washing And Screening Plant


Sand washing and screening plant is designed based on the sand trommel screening machine, sand washing machine and fine sand recovery machine. It adopts advanced technology. It has simple structure and various functions. It is widely used for crushed sand, river sand, mountain sand, Lake sand or sea sand, as well as mining, aggregate processing, pile driving mud, river desilting treatment, urban construction waste incineration, ceramic raw material processing, silica sand production and processing, various metals Cleaning, screening, recovery and dewatering operations in many industries, such as mine tailings treatment.


Performance advantages:

1.Higher sand content and lower water content.

2.Recover 0.16-3mm fine sand to reduce mud content.

3.Compact structure and convenient installation.

4.High productivity and 95% of fine particles in raw materials can be recycled.

5.Solve the problem of sedimentation tank cleaning and improve the economic performance.

Working principle:

After the belt, reducer and gear are decelerated, the motor and impeller run slowly. Sand and water flow from the feed tank into the sink, roll with the impeller and grind each other. The impurities covering the sand are washing away. At the same time, adding more water, the strong water flow will take away the waste in the washing tank and some low weight waste, which is the whole washing process. Clean sand and stones are picked up by the leaves. When it rises slowly, water begins to fall through the screen and fall back into the sink. On the one hand, water is removed from the sand and stone; on the other hand, water can be fully utilized. Finally, sand and stone from the rotary impeller into the outside of the sink, complete the washing task.
